Etrans-T09 Temperature Transmitter
Enelsan Etrans-T09
Description
-
Overview: The ETRANS T09 is a compact, battery-powered digital thermometer designed for high-precision measurements.
-
Design: It features a durable stainless steel body, a hermetically sealed sensor for harsh environments, and a large backlit display with a user-friendly menu.
-
Versatility: Ideal for industrial processes, HVAC, food production, and labs. Its modular design allows for easy battery/electronics replacement, ensuring long-term energy independence.
|
Feature |
Description |
|---|---|
|
Measurement Range |
-200°C to +850°C | Device Body: -40°C to +85°C. |
|
Accuracy |
± 0.5% reference accuracy (for PT100) with selectable 0.001 or 0.1 resolution. |
|
Sensor Type |
PT100 Platinum Chip Sensor (Class B/Class A) embedded in stainless steel. |
|
Material |
Housing and process connections are made of 316L Stainless Steel. |
|
Display |
5-digit backlit LCD with user-selectable units (°C, °F, °K). |
|
Battery Life |
Over 10 years using a 3.6 VDC Lithium battery, supported by an automatic sleep mode to save power |
|
Protection Class |
IP65 (dust and splash-proof) with a condensation-protected internal design. |
|
Outputs & Alarms |
Includes two NPN alarm outputs (max 80Vdc, 50mA) and records minimum/maximum measurement values. |
